LED Emergency Backlit Flat Panel; 2 ft. x 4 ft.; Wattage and CCT Selectable; 100-347 Volt; (A65TU)
$539.00
Call For Price
Enlarge Image
Add to Cart
Description:
LED Emergency Backlit Flat Panel; 2 ft. x 4 ft.; Wattage and CCT Selectable; 100-347 Volt; ColorQuick Technology; PowerQuick Technology
Availability:
  • Manufacturer may be Out Of Stock.
Required Components:

Optional Accessory:

Dimensions:
right arrow Height: 2.88"
right arrow Width: 23.75"
Additional Details:
right arrow Finish: White
right arrow Category: Flat Panel
right arrow Sub Category: Backlit Emergency
right arrow Style: Utility
right arrow Additional Info: Driver Specs - VDC38-48V; 630/810/1030mA
right arrow Avg Rated Hours: 50000
right arrow Bulb Shape1: Integrated LED
right arrow Bulb Type1: LED
right arrow Color Temperature: Warm to Cool White
right arrow Dimmable: Yes-Dimmable
right arrow Each Height: 25.2
right arrow Each Length: 49.02
right arrow Each Width: 4.33
right arrow Length: 47.72
right arrow Lumens: 3300L-5750L
right arrow Tariff Code: 9405.11.6020
right arrow Warranty: 5 Year Limited - Fixtures
right arrow Wire Length: 3.54
right arrow Air Tight: No
right arrow Amps: 0.300-0.086/0.400-0.115/0.500-0.144A
right arrow ANSI Base: Integrated
right arrow BAA Compliant: No
right arrow Beam Angle: 120
right arrow CA Prop-65: Lead
right arrow CCT Selectable: Yes
right arrow CEC: T20 Exempt - Fixtures Not Regulated
right arrow CEC Terse: Lawful for sale in California
right arrow CEC Web Text: Lawful for sale
right arrow Connection: Hardwire
right arrow Country Of Origin: Vietnam
right arrow CRI: 80+
right arrow Dimmable Down To: 100 to 20 percent
right arrow Dimmable Function: 0-10V Dimming Only
right arrow DLC Classification: Standard
right arrow DLC Primary Use: 2x4 Luminaires for Ambient Lighting of Interior Commercial Spaces; Low-Bay Luminaires for Commercial and Industrial Buildings
right arrow Each Cube: 3.0954
right arrow Each Quantity: 1
right arrow Efficacy: 110.00/113.13/115.00 LPW
right arrow FCC Compliant: Yes
right arrow Feature 1: 3500K/4000K/5000K CCT Selectable
right arrow Feature 2: 30W/40W/50W Wattage Selectable
right arrow Feature 3: Integrated emergency battery backup with 90-minute run time
right arrow Feature 4: Flicker Free, Even Light Distribution
right arrow Feature 5: 0-10V Dimmable
right arrow Feature 6: 50,000 average rated hours of use
right arrow Feature 7: DLC Listed
right arrow Feature 8: Higher 120-347 Voltage Range
right arrow Finish Family: White
right arrow Fixture shape: Square
right arrow Flicker Free: Yes
right arrow Has Emergency Battery: Yes
right arrow IC Rated: Yes
right arrow Incandescent Equivalent: 150W-175W
right arrow Indoor Outdoor: Indoor
right arrow IOT Enabled: No
right arrow IP Rating: IP20
right arrow JA8 Compliant: No
right arrow Lens Finish: Frost
right arrow Lens Material: Poly methyl methacrylate (PMMA)
right arrow Long Description: SATCO NUVO's LED Backlit 2X4 Flat Panel 65-586R1 features our new ColorQuick and PowerQuick technologies. With three popular wattages and three different CCT options available, customers can choose from nine possible power and color configurations at t
right arrow Material: Aluminum / Steel
right arrow Mounting Procedure: Ceiling
right arrow NSF Approved: Yes
right arrow Operating Frequency: 50/60Hz
right arrow Operating Temp: -17C (+1.4F) to +45C (+113F)
right arrow Order In Multiples Of: 1
right arrow Pack Type: Box
right arrow Panel Size: 2x4
right arrow Photocell: No Photocell
right arrow Power Factor: 0.9
right arrow Quantity In Pack: 1
right arrow Replaceable Light Source: No
right arrow RoHS Compliant: Yes
right arrow Romance Copy: SATCO NUVO's LED Backlit Panel fixtures feature our new ColorQuick and PowerQuick technologies in a variety of sizes. With three popular wattages and three different CCT options available, customers can choose from nine possible power and color configu
right arrow Safety Listing: cETLus - Listed
right arrow SDS class: LED_Fixture
right arrow Short Description: 2X4 LED EM BACKLIT FLAT PANEL
right arrow Temperature (CCT): 3500K/4000K/5000K
right arrow Title 20 Compliant: Exempt
right arrow Title 24 Compliant: No
right arrow Total Harmonic Distortion: <20%
right arrow Wattage Selectable: Yes
right arrow Weight Lb.: 11.46
right arrow Wire Gauge: 14
right arrow Wire Temp Rating: 80C (176F)
right arrow Standard Category: Specialty Items
right arrow Standard Subcategory: Lighting Accessories
right arrow Standard Option: LED , Prop 65 prop65.png
right arrow Standard Lumens: 3300+
right arrow Standard Kelvin: 4001-4500
Internal #:
A65TU
